[scroll down for specs]
ENGINE NAME
• Vanguard Big Block EFI/ETC with Oil Guard
HORSEPOWER
• 40HP
FUEL CAPACITY
• 16gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTG Transaxles - 16cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 498 ft-lb | Max Torque - 587 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 24x14-R12 Michelin Tweels®
FRONT TIRES
• 13x6.5-R6 Michelin Tweels®
WHEELS TYPE
• Michelin Tweels®
SPEED (F/R)
• Forward - Up to 15mph | Reverse - Up to 6mph
• FEATURES
SEAT
• Supreme Custom Blackout Seat - Adjustable TecsPak Elastomer supports - 360 degree floating seat platform
STEERING LEVERS
• Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
CONTROL PANEL LED WARNING INDICATORS
• Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
IGNITION
• Keyless, Personal Code activated
AUXILIARY POWER
• 12v Outlet
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• 2” Rear Receiver Standard
• CUTTING DECK
DECK SIZES
• 61", 72"
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 61” Deck - 62.5” Wide | 72” Deck - 73.5” Wide
WEIGHT
• 1310lbs
LENGTH
• 84”
HEIGHT
• 75" with ROPS Up - 54" with Folding ROPS Down
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 500 Hour Residential - 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 1500 Hour
CONTROL PANEL WARRANTY
• 3 Year
[scroll down for specs]
ENGINE NAME
• Kawasaki FX1000E
HORSEPOWER
• 38.5HP
FUEL CAPACITY
• 9.5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTG Transaxles - 16cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 498 ft-lb | Max Torque - 587 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 61" , 72" - 24x14-R12 Radial
FRONT TIRES
• 13x6.5-R6 Radial with Optional No Flats, or Tweels
WHEELS TYPE
• Aluminum rear wheels and front hub covers
SPEED (F/R)
• Forward - Up to 13mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Smart Ride Technology w/ full suspension seat - adjustable TecsPak Elastomer supports - 360 degree floating seat platform - indepentant rear frame section suspended by Winamac coil springs
STEERING LEVERS
• Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• N/A
CONTROL PANEL LED WARNING INDICATORS
• N/A
IGNITION
• Key Switch
AUXILIARY POWER
• 12v Outlet Next to Phone Holder
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• 2" Rear Receiver Standard
• CUTTING DECK
DECK SIZES
• 61”, 72”
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 61” Deck - 62.5” Wide | 72” Deck - 73.5” Wide
WEIGHT
• 61” Deck - 1290lbs | 72” Deck - 1323lbs
LENGTH
• 84”
HEIGHT
• 75" with ROPS Up - 54" with Folding ROPS Down
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 500 Hours Residential - 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 1500 Hour
CONTROL PANEL WARRANTY
• N/A
[scroll down for specs]
ENGINE NAME
• Kawasaki FX801
HORSEPOWER
• 25.5HP
FUEL CAPACITY
• 9.5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTJ Transaxles - 12cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 54" - 24x10.50-R12 Radial | 61" - 24x14-R12 Radial
FRONT TIRES
• 13x6.5-R6 Radial with Optional No Flats, or Tweels
WHEELS TYPE
• Aluminum rear wheels and front hub covers
SPEED (F/R)
• Forward - Up to 13mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Smart Ride Technology w/ full suspension seat - adjustable TecsPak Elastomer supports - 360 degree floating seat platform - indepentant rear frame section suspended by Winamac coil springs
STEERING LEVERS
• Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• N/A
CONTROL PANEL LED WARNING INDICATORS
• N/A
IGNITION
• Key Switch
AUXILIARY POWER
• 12v Outlet Next to Phone Holder
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• 2” Rear Receiver Standard
• CUTTING DECK
DECK SIZES
• 54”, 61”
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 61” Deck - 62.5” wide | 72” Deck - 73.5” wide
WEIGHT
• 61” Deck - 1192lbs | 72” Deck - 1216lbs
LENGTH
• 84”
HEIGHT
• 75" with ROPS Up - 54" with Folding ROPS Down
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 500 Hour Residential - 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 1500 Hour
CONTROL PANEL WARRANTY
• N/A
[scroll down for specs]
ENGINE NAME
• Kawasaki FX1000
HORSEPOWER
• 37HP
FUEL CAPACITY
• 9.5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTJ Transaxles - 12cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 54" - 24x10.50-R12 Radial | 61", 72" - 24x12-R12 Radial
FRONT TIRES
• 13x6.5-R6 Radial with Optional No Flats, or Tweels
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 11mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Full Suspension Seat with Adjustable TecsPak Elastomer supports and 360 degree Floating Seat Platform
STEERING LEVERS
• Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• N/A
CONTROL PANEL LED WARNING INDICATORS
• N/A
IGNITION
• Key Switch
AUXILIARY POWER
• 12v Outlet Next to Phone Holder
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• 2” Rear Receiver Standard
• CUTTING DECK
DECK SIZES
• 54”, 61”, 72”
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 54” Deck - 55.5” wide | 61” Deck - 62.5” wide | 72” Deck - 73.5” wide
WEIGHT
• 54” Deck - 1108lbs | 61” Deck - 1138lbs | 72” Deck - 1170lbs
LENGTH
• 84”
HEIGHT
• 75" with ROPS Up - 54" with Folding ROPS Down
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 1500 Hour
CONTROL PANEL WARRANTY
• N/A
[scroll down for specs]
ENGINE NAME
• Kawasaki FT703V
HORSEPOWER
• 24HP
FUEL CAPACITY
• 9.5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Tuff Torq TZT - 13cc
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 54" - 24x10.50-R12 Radial | 61" - 24x12-R12 Radial
FRONT TIRES
• 13x6.5-R6 Smooth Tread with Optional Radial Upgrade, No Flats, or Tweels
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 9mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Dymetrol Seat with 360 Degree Floating Seat Platform
STEERING LEVERS
• Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• N/A
CONTROL PANEL LED WARNING INDICATORS
• N/A
IGNITION
• Key Switch
AUXILIARY POWER
• 12v Outlet Next to Phone Holder
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• 2" Rear Receiver Standard
• CUTTING DECK
DECK SIZES
• 54", 61"
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist.
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 54” Deck - 55.5” wide | 61” Deck - 62.5” wide
WEIGHT
• 54” Deck - 1052lbs | 61” Deck - 1095lbs
LENGTH
• 84"
HEIGHT
• 75” with ROPS up (54” with Folding ROPS down)
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 750 Hour
CONTROL PANEL WARRANTY
• N/A
[scroll down for specs]
ENGINE NAME
• Kawasaki FR691V
HORSEPOWER
• 23HP
FUEL CAPACITY
• 9.5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTE Transaxles - 10cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1,000 Hours Between Oil Change
DRIVE TIRES
• 48" - 22x10-R10 Radial | 54" - 22x12 - R10 Radial
FRONT TIRES
• 13x6.5-R6 Smooth Tread with Optional Radial Upgrade
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 9mph | Reverse - Up to 5mph
• FEATURES
SEAT
• 360 Degree Floating Seat Platform
STEERING LEVERS
• Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• N/A
CONTROL PANEL LED WARNING INDICATORS
• N/A
IGNITION
• Key Switch
AUXILIARY POWER
• 12v Outlet
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 48", 54"
DECK DEPTH
• 5" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 48” Deck - 49.5” Wide | 54” Deck - 55.5” Wide
WEIGHT
• 907 - 1,095 lbs
LENGTH
• 84"
HEIGHT
• 75" with ROPS Up - 54" with Folding ROPS Down
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 400 Hour - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 750 Hour
CONTROL PANEL WARRANTY
• N/A
[scroll down for specs]
ENGINE NAME
• Kawasaki FR730V
HORSEPOWER
• 23HP
FUEL CAPACITY
• 9.5 gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTE Transaxles - 10cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1,000 Hours Between Oil Change
DRIVE TIRES
• 24" Radial
FRONT TIRES
• 13" Bias Ply
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 9mph Reverse - Up to 5mph
• FEATURES
SEAT
• Dymetrol Adjustable 3" Travel Seat with 360-Degree Floating Seat Platform
STEERING LEVERS
• Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
CONTROL PANEL LED WARNING INDICATORS
• Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
IGNITION
• Multi-Function Keypad with Soft Start
AUXILIARY POWER
• 12V Outlet
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 54", 61"
DECK DEPTH
• 5" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 5" with 15 Cut Heights
BLADE SPINDLES
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 54" Deck - 55.5" Wide | 61" Deck - 62.5" Wide
WEIGHT
• 922 - 942 lbs
LENGTH
• 84"
HEIGHT
• 75" with ROPS Up - 54" with Folding ROPS Down
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 400 Hour - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 750 Hour
CONTROL PANEL WARRANTY
• 3 Year
[scroll down for specs]
ENGINE NAME
• Kawasaki FR691V
HORSEPOWER
• 23HP
FUEL CAPACITY
• 5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Tuff Torq 450 Series
HYDRAULIC DRIVE TORQUE
• Continuous - 118 ft-lb | Max Torque - 295 ft-lb
HYDRO DRIVE MAINTENANCE
• 200 Hours Between Oil Changes (when heavily used)
DRIVE TIRES
• 54" - 22x11-10 Turf Armor
FRONT TIRES
• 13x6.5-R6 Smooth Tread
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 8.5mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Comfortable, Custom Design, with seat platform shock
STEERING LEVERS
• Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• N/A
CONTROL PANEL LED WARNING INDICATORS
• N/A
IGNITION
• Key Switch
AUXILIARY POWER
• 12v Outlet
STORAGE
• Large Cup Holder & Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 54”
DECK DEPTH
• 5" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Magnetic Pin Height Adjustment
CUT HEIGHT
• 1" to 4.25" with 12 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 54” Deck - 55.5” Wide
WEIGHT
• 820lbs
LENGTH
• 81"
HEIGHT
• 46"
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 300 Hour - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 300 Hour
CONTROL PANEL WARRANTY
• N/A
[scroll down for specs]
ENGINE NAME
• Kawasaki FR651V
HORSEPOWER
• 21.5HP
FUEL CAPACITY
• 5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Tuff Torque 300 Series
HYDRAULIC DRIVE TORQUE
• Continuous - 118 ft-lb | Max Torque - 295 ft-lb
HYDRO DRIVE MAINTENANCE
• 200 Hours Between Oil Changes (when heavily used)
DRIVE TIRES
• 42" - 20x7-10 Turf Armor
FRONT TIRES
• 13x6.5-R6 Smooth Tread
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 7.5mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Comfortable, Custom Design
STEERING LEVERS
• Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
CONTROL PANEL LED WARNING INDICATORS
• Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
IGNITION
• Keyless, Personal Code Activated
AUXILIARY POWER
• 12v Outlet
STORAGE
• Large Cup Holder & Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 42"
DECK DEPTH
• 4" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated
DECK ADJUSTMENT
• Change-On-The-Go Precision Deck Height Dial
CUT HEIGHT
• Quick Adjust Dial from 1" to 4.25" with 12 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 43.5"
WEIGHT
• 682 - 719 lbs
LENGTH
• 81”
HEIGHT
• 44”
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 300 Hour - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the Leading Edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 200 Hour
CONTROL PANEL WARRANTY
• 3 Year
[scroll down for specs]
ENGINE NAME
• Kawasaki FR651V
HORSEPOWER
• 21.5HP
FUEL CAPACITY
• 5gal
• DRIVE LINE
HYDRAULIC DRIVE
• Tuff Torque 300 Series
HYDRAULIC DRIVE TORQUE
• Continuous - 118 ft-lb | Max Torque - 295 ft-lb
HYDRO DRIVE MAINTENANCE
• 200 Hours Between Oil Changes (when heavily used)
DRIVE TIRES
• 42" - 20x7-10 Turf Armor
FRONT TIRES
• 13x6.5-R6 Smooth Tread
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 7.5mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Comfortable, Custom Design
STEERING LEVERS
• Adjustable Up and Down
CONTROL PANEL LCD DISPLAY
• Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
CONTROL PANEL LED WARNING INDICATORS
• Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
IGNITION
• Keyless, Personal Code Activated
AUXILIARY POWER
• 12v Outlet
STORAGE
• Large Cup Holder & Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 42"
DECK DEPTH
• 4" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated
DECK ADJUSTMENT
• Change-On-The-Go Precision Deck Height Dial
CUT HEIGHT
• Quick Adjust Dial from 1" to 4.25" with 12 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Foot Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 43.5"
WEIGHT
• 682 - 719 lbs
LENGTH
• 81”
HEIGHT
• 44”
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 3 Year / 300 Hour - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the Leading Edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 200 Hour
CONTROL PANEL WARRANTY
• 3 Year
[scroll down for specs]
ENGINE NAME
• Kawasaki FX801V
HORSEPOWER
• 25.5HP
FUEL CAPACITY
• 12gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTJ Transaxles - 12cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 54" - 24x10.50-R12 Radial | 61" - 24x12-R12 Radial
FRONT TIRES
• 13x6.5-R6 Radial with Optional No Flats, or Tweels
WHEELS TYPE
• Aluminum rear wheels
SPEED (F/R)
• Forward - Up to 11mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Smart Ride Technology w/ full suspension operator platform w/ supporting reinforced knee bolstering - adjustable TecsPak Elastomer rolling on radial tires w/ optional fully adjustable suspension seat system.
STEERING LEVERS
• Adjustable Speed Stops
CONTROL PANEL LCD DISPLAY
• Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time between Oil Change Countdown - Fault Codes
CONTROL PANEL LED WARNING INDICATORS
• Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
IGNITION
• Keyless, Personal Code activated
AUXILIARY POWER
• 12v Outlet Next to Phone Holder
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 54", 61"
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Precision Deck Height Pin System
CUT HEIGHT
• Quick Adjust Dial from 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Hand Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 54” Deck - 55.5” Wide | 61” Deck - 62.5” Wide
WEIGHT
• 54” Deck - 1076lbs | 61” Deck - 1109lbs
LENGTH
• 72.5"
HEIGHT
• 49"
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 1500 Hour
CONTROL PANEL WARRANTY
• 3 Year
[scroll down for specs]
ENGINE NAME
• Kawasaki FT730V
HORSEPOWER
• 24HP
FUEL CAPACITY
• 12gal
• DRIVE LINE
HYDRAULIC DRIVE
• Parker HTE Transaxles - 10cc Drive Motors
HYDRAULIC DRIVE TORQUE
• Continuous - 262 ft-lb | Max Torque - 406 ft-lb
HYDRO DRIVE MAINTENANCE
• 1000 Hours Between Oil Changes
DRIVE TIRES
• 54" - 24x10.50-R12 Radial | 61" - 24x12-R12 Radial
FRONT TIRES
• 13x6.5-R6 Smooth Tread with Optional Radial Upgrade, No Flats, or Tweels
WHEELS TYPE
• Steel
SPEED (F/R)
• Forward - Up to 9mph | Reverse - Up to 5mph
• FEATURES
SEAT
• Smart Ride Technology w/ full suspension operator platform w/ supporting reinforced knee bolstering - adjustable TecsPak Elastomer rolling on radial tires w/ optional fully adjustable suspension seat system.
STEERING LEVERS
• Adjustable Speed Stops
CONTROL PANEL LCD DISPLAY
• Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
CONTROL PANEL LED WARNING INDICATORS
• Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
IGNITION
• Keyless, Personal Code activated
AUXILIARY POWER
• 12v Outlet Next to Phone Holder
STORAGE
• Phone Holder, Cup Holder, and Deep Storage Tray
HITCH
• N/A
• CUTTING DECK
DECK SIZES
• 54", 61"
DECK DEPTH
• 6" Deep, Reinforced 7 Gauge Full-Floating Deck
DECK LIFT
• Foot Operated with Shock Assist
DECK ADJUSTMENT
• Precision Deck Height Pin System
CUT HEIGHT
• Quick Adjust Dial from 1" to 5" with 15 Cut Heights
BLADE SPINDLES
• Cast Aluminum, No Maintenance/Sealed Bearings
PARKING BRAKE
• Hand Operated
FRAME
• 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
• MEASUREMENTS
WIDTH
• 54” Deck - 55.5” Wide | 61” Deck - 62.5” Wide
WEIGHT
• 54” Deck - 1011lbs | 61” Deck - 1044lbs
LENGTH
• 72.5"
HEIGHT
• 49"
• WARRANTY
ENGINE WARRANTY
• 3 Year
FULL WARRANTY
• 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
DECK WARRANTY
• Lifetime on the leading edge
HYDRAULIC DRIVE WARRANTY
• 3 Year / 750 Hour
CONTROL PANEL WARRANTY
• 3 Year
Copyright © 2024 WNY Accessory Shop
All Rights Reserved
