With Gravely's Zero Turn, Walk-Behind, Stand-On, and Electric models of lawn maintenance equipment, it's a natural extension for us as we also offer equipment trailers. Gravley equipment is proudly made in the U.S.A. and has been in business since 1916.
PRO-STANCE 32
[scroll down for specs]
Engine: Kawasaki® FS600V
Horsepower: 18.5
Engine Displacement: 36.8 in / 603 cc
Fuel System: Gas
Fuel Capacity: 6 gal / 22.7 ltr
Drive System: Hydro-Gear® ZT-3100® Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 8 mph / 12.9 kph
Ground Speed Reverse: 3 mph / 4.8 kph
Wheels Front: 11.0 x 4.0 in - 5.0 in
Wheels Rear: 18.0 x 8.5 in - 8.0 in
Battery Capacity: 300 CCA
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 32 in / 81.3 cm
Coverage Hour: 2.6 acres / 1.1 hectares
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 32 in / 81.3 cm
Weight (Assembled): 762 lb / 345.6 kg
Length: 64 In / 162.6 cm
Width: 32 in / 81.3 cm
Width (Chute Up): 33.5 in / 85.1 cm
Width (Chute Down): 49 in / 124.5 cmPRO-STANCE 36
[scroll down for specs]
Engine: Kawasaki® FS600V
Horsepower: 18.5
Engine Displacement: 36.8 in / 603 cc
Fuel System: Gas
Fuel Capacity: 6 gal / 22.7 ltr
Drive System: Hydro-Gear® ZT-3100® Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 8 mph / 12.9 kph
Ground Speed Reverse: 3 mph / 4.8 kph
Wheels Front: 11.0 x 4.0 in - 5.0 in
Wheels Rear: 18.0 x 8.5 in - 8.0 in
BATTERY CAPACITY: 300 CCA
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 36 in / 91.4 cm
Coverage Hour: 2.9 acres / 1.2 hectares
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 36 in / 91.4 cm
Weight (Assembled): 776 lb / 351.9 kg
Length: 64 In / 162.6 cm
Width: 36 in / 91.4 cm
Width (Chute Up): 36.5 in / 92.7 cm
Width (Chute Down): 49 in / 124.5 cmPRO-STANCE 48
[scroll down for specs]
Engine: Kawasaki® FX730V
Horsepower: 23.5
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 9 gal / 34.1 ltr
Drive System: Hydro-Gear® ZT-3400 Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 9 mph / 14.5 kph
Ground Speed Reverse: 3 mph / 4.8 kph
Wheels Front: 13.0 x 6.5 in - 6.0 in
Wheels Rear: 20.0 x 10.5 in - 8.0 in
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 48 in / 121.9 cm
Coverage Hour: 4.3 acres / 1.7 hectares
Spindle Type: Mechanical
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 48 in / 121.9 cm
Weight (Assembled): 875 lb / 396.8 kg
Length: 63.5 In / 161.3 cm
Width: 48 in / 121.9 cm
Width (Chute Up): 50 in / 127 cm
Width (Chute Down): 63.2 in / 160.5 cm
PRO-STANCE 52
[scroll down for specs]
Engine: Kawasaki® FX730V
Horsepower: 23.5
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 9 gal / 34.1 ltr
Drive System: Hydro-Gear® ZT-3400 Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 9 mph / 14.5 kph
Ground Speed Reverse: 4 mph / 6.4 kph
Wheels Front: 13.0 x 6.5 in - 6.0 in
Wheels Rear: 20.0 x 10.5 in - 8.0 in
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 52 in / 132.1 cm
Coverage Hour: 4.7 acres / 1.9 hectares
Spindle Type: Mechanical
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 52 in / 132.1 cm
Weight (Assembled): 912 lb / 413.6 kg
Length: 63.5 In / 161.3 cm
Width: 52 in / 132.1 cm
Width (Chute Up): 55.5 in / 141 cm
Width (Chute Down): 67.5 in / 171.5 cmPRO-STANCE 52 EFI
[scroll down for specs]
Engine: Kawasaki® FT730V-EFI
Horsepower: 26
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 9 gal / 34.1 ltr
Drive System: Hydro-Gear® ZT-3400 Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 9 mph / 14.5 kph
Ground Speed Reverse: 4 mph / 6.4 kph
Wheels Front: 13.0 x 6.5 in - 6.0 in
Wheels Rear: 20.0 x 10.5 in - 8.0 in
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 52 in / 132.1 cm
Coverage Hour: 4.7 acres / 1.9 hectares
Spindle Type: Mechanical
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 52 in / 132.1 cm
Weight (Assembled): 912 lb / 413.6 kg
Length: 63.5 In / 161.3 cm
Width: 52 in / 132.1 cm
Width (Chute Up): 55.5 in / 141 cm
Width (Chute Down): 67.5 in / 171.5 cmPRO-STANCE 60
[scroll down for specs]
Engine: Kawasaki® FX730V
Horsepower: 23.5
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 9 gal / 34.1 ltr
Drive System: Hydro-Gear® ZT-3400 Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 9 mph / 14.5 kph
Ground Speed Reverse: 4 mph / 6.4 kph
Wheels Front: 13.0 x 6.5 in - 6.0 in)
Wheels Rear: 20.0 x 10.5 in - 8.0 in
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 60 in / 152.4 cm
Coverage Hour: 5.4 acres / 2.2 hectares
Spindle Type: Mechanical
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 60 in / 152.4 cm
Weight (Assembled): 940 lb / 426.3 kg
Length: 63 In / 160 cm
Width: 60 in / 152.4 cm
Width (Chute Up): 63 in / 160 cm
Width (Chute Down): 75.3 in / 191.1 cm
PRO-STANCE 60 EFI
[scroll down for specs]
Engine: Kawasaki® FT730V-EFI
Horsepower: 26
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 9 gal / 34.1 ltr
Drive System: Hydro-Gear® ZT-3400 Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 9 mph / 14.5 kph
Ground Speed Reverse: 4 mph / 6.4 kph
Wheels Front: 13.0 x 6.5 in - 6.0 in
Wheels Rear: 20.0 x 10.5 in - 8.0 in
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 60 in / 152.4 cm
Coverage Hour: 5.4 acres / 2.2 hectares
Spindle Type: Mechanical
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 60 in / 152.4 cm
Weight (Assembled): 940 lb / 426.3 kg
Length: 63 In / 160 cm
Width: 60 in / 152.4 cm
Width (Chute Up): 63 in / 160 cm
Width (Chute Down): 75.3 in / 191.1 cm
Z-STANCE 32
[scroll down for specs]
Engine: Kawasaki® FS600V
Horsepower: 18.5
Engine Displacement: 36.8 in / 603 cc
Fuel System: Gas
Fuel Capacity: 4.5 gal / 17 ltr
Drive System: Hydro-Gear® ZT-3100® Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 7 mph / 11.3 kph
Ground Speed Reverse: 3 mph / 4.8 kph
Wheels Front: 11.0 x 5.0 in - 6.0 in
Wheels Rear: 20.0 x 6.5 in - 8.0 in
Charger Type: Standard
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 32 in / 81.3 cm
Coverage Hour: 2.2 acres / 0.9 hectares
Spindle Type: Mechanical
Deck Material: 7 ga
Deck Construction: Fabricated X-Factor ® II
Discharge Configuration: Side
Cutting Height Min: 2 in / 5.1 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 32 in / 81.3 cm
Weight (Assembled): 669 lb / 303.4 kg
Length: 65.5 In / 166.4 cm
Width: 32 in / 81.3 cm
Width (Chute Up): 32.8 in / 83.3 cm
Width (Chute Down): 44.8 in / 113.8 cmZ-STANCE 48
[scroll down for specs]
Engine: Kawasaki® FS651V
Horsepower: 22
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 4.5 gal / 17 ltr
Drive System: Hydro-Gear® ZT-3100® Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 7 mph / 11.3 kph
Ground Speed Reverse: 3 mph / 4.8 kph
Wheels Front: 11.0 x 6.0 in - 5.0 in
Wheels Rear: 20.0 x 10.0 in - 8.0 in
Charger Type: Standard
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 48 in / 121.9 cm
Coverage Hour: 3.4 acres / 1.4 hectares
Spindle Type: Mechanical
Deck Material: 10 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 48 in / 121.9 cmZ-STANCE 52
[scroll down for specs]
Engine: Kawasaki® FS651V
Horsepower: 22
Engine Displacement: 44.3 in / 725.9 cc
Fuel System: Gas
Fuel Capacity: 4.5 gal / 17 ltr
Drive System: Hydro-Gear® ZT-3100® Transaxles
Transmission Type: Hydrostatic
Brake Type: Lever Activated Parking
Driver Position: Stand
Ground Speed Forward: 7 mph / 11.3 kph
Ground Speed Reverse: 3 mph / 4.8 kph
Wheels Front: 11.0 x 6.0 in - 5.0 in
Wheels Rear: 20.0 x 10.0 in - 8.0 in
Charger Type: Standard
Battery Capacity: 300 CCA
Number Of Batteries: 1
Battery Voltage: 12
Battery Type: Lead Acid - Maintenance Free
Battery Size: U1
Deck Size: 52 in / 132.1 cm
Coverage Hour: 3.6 acres / 1.5 hectares
Spindle Type: Mechanical
Deck Material: 10 ga
Deck Construction: Fabricated X-Factor® 3
Discharge Configuration: Side
Cutting Height Min: 1.5 in / 3.8 cm
Cutting Height Max: 5 in / 12.7 cm
Cutting Width: 52 in / 132.1 cm
Weight (Assembled): 763 lb / 346 kg
Length: 65.5 In / 166.4 cm
Width: 52 in / 132.1 cm
Width (Chute Up): 55 in / 139.7 cm
Width (Chute Down): 66.8 in / 169.5 cm
